Lineardraft is a 3D BIM software solution; the most efficient way to design overhead line electrification.

The core principle of Lineardraft is simple: use intuitive design tools and automation to significantly reduce cost and increase capacity, all whilst maintaining capability and assurance.

Lineardraft allows the simultaneous design of 2D layouts & 3D models, has powerful automation tools allowing for complex change in seconds, and produces data-rich assets with customisable outputs, facilitating a seamless design-to-build transition helping the industry move towards standardisation.

---

Revolutionise your workflow. Reduce costs. Here’s how…

Parametric Design - Switch between 2D & 3D on-the-fly, with changes applied to both as you work. Speed up your workflow, reduce work effort, and eliminate error.

Data-rich Assets - Lineardraft automatically creates and updates asset data with every click. Collaborate across teams with ease.

Automated Change - Powerful automation tools allow you make complex changes in seconds, freeing engineers to focus on what’s critical.

Any Design Range - It’s not enough to have the tools, you need the materials to build with. That’s where our 3D BIM design catalogues come in.

Customise Outputs - Generate layout drawings, BOM, BOQ, and rich reports. Use configurable project settings to completely customise your outputs.

---

Lineardraft has already been used on HS2, the Transpennine Route Upgrade, Midland Main Line Upgrade, Wales & Borders – Core Valley Lines, and the Fife Electrification project, among other worldwide projects.
